Spoke Set Honda CB 750 Hondamatic 18-inch 76-77 Rear Wheel
1,190 SEK per Set
CC Products spokes are made in our spoke machine in our own factory in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-0456
CC Products stainless spoke set
Fits the following modeller:
HONDA
CB 650 80-82
CB 750 76-77 (Hondamatic)
CB 750 69-82
For 18-inch rear wheel with these hubs:
42601-300-020
42601-300-030
42601-300-040
42601-300-050
42601-425-670
The hubs have 180 mm diameter of the brake drum, 80 mm inner diameter of the rear sprocket and 110 mm pitch of the sprocket bolts.
This spoke set has 40 spokes with spoke nipples.
Spoke size: 20 spokes of 142 mm, outer spoke on both sides.
OEM Ref. 42607-300-003 replaced by 42607-341-000.
Spoke size: 20 spokes of 142,5 mm, inner spoke on both sides.
OEM Ref. 42606-300-003 replaced by 42606-341-000 replaced by 97313-69125R0.
This spoke set is available in 3,6 mm (Standard) and 4 mm (heavy duty).
Nipple size: 7,0x20 mm. (275)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 142 mm, have article number 50-0456-1
One spoke and nipple, 142,5 mm, have article number 50-0456-2
Fits the following modeller:
HONDA
CB 650 80-82
CB 750 76-77 (Hondamatic)
CB 750 69-82
For 18-inch rear wheel with these hubs:
42601-300-020
42601-300-030
42601-300-040
42601-300-050
42601-425-670
The hubs have 180 mm diameter of the brake drum, 80 mm inner diameter of the rear sprocket and 110 mm pitch of the sprocket bolts.
This spoke set has 40 spokes with spoke nipples.
Spoke size: 20 spokes of 142 mm, outer spoke on both sides.
OEM Ref. 42607-300-003 replaced by 42607-341-000.
Spoke size: 20 spokes of 142,5 mm, inner spoke on both sides.
OEM Ref. 42606-300-003 replaced by 42606-341-000 replaced by 97313-69125R0.
This spoke set is available in 3,6 mm (Standard) and 4 mm (heavy duty).
Nipple size: 7,0x20 mm. (275)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 142 mm, have article number 50-0456-1
One spoke and nipple, 142,5 mm, have article number 50-0456-2
