Spoke Set Honda XLX 250 R 21-inch 1984 Front Wheel
1,090 SEK per Set
CC Products spokes are made in our spoke machine in our own factory in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-0386
CC Products stainless spoke set
Fits the following models:
HONDA
CR 125 R 1982
CR 250 R 1982
CR 480 R 1982
XL 250 R 82-83
XL 500 R 1982
XLX 250 R 1984
XR 250 R 1983
For 21-inch front wheel with these hubs:
CR 125-500 R: 44601-KA4-700 replaced by 44601-KA4-701.
XL 250 R: 44601-KB7-000
XL 500 R: 44601-KA4-700 replaced by 44601-KA4-701.
XLX 250 R: 44601-KB7-940
This spoke set has 36 spokes with spoke nipples.
Spoke size: 18 spokes of 3,6x198 mm, left side.
OEM Ref. 446B0-KA4-700 (CR 125-480)
OEM Ref. 446B0-MC4-000 (XL 250/500 R)
OEM Ref. 446B0-KA6-740 (XR 250 R)
Spoke size: 18 spokes of 3,6x238 mm, right side.
OEM Ref. 446A0-KA4-700 (CR 125-480)
OEM Ref. 446A0-MC4-000 (XL 250/500 R)
OEM Ref. 446A0-KA6-740 (XR 250 R)
21x1,60 Excel rim with article number 58-840 fits this spoke set.
Nipple size: 7,0x20 mm. (9G/275)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,6x198 mm, have article number 50-0386-1
One spoke and nipple, 3,6x238 mm, have article number 50-0386-2
