Spoke Set Yamaha XT 660 X 17x2.50/2.75 04-18 Rear Wheel
1,090 SEK per Set
CC Products spokes are made in our spoke machine in our own factory in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-0605
CC Products stainless spoke set
Fits the following models:
YAMAHA
XT 660 R 04-18
XT 660 X 04-18
XT 660 Z Ténéré 08-16
For 17x2,50 and 17x2,75 rear wheel with hub 5VK-25311-00 and 56P-F5311-00.
This spoke set has 36 spokes with spoke nipples.
NOTE! For MT rim profile.
Spoke size: 18 spokes of 3,6x164 mm. Inner and outer on sprocket side.
Spoke size: 18 spokes of 3,6x169 mm. Inner and outer on brake disc side.
OEM Ref. 5VK-F5304-00 replaced by 5VK-F5304-01 (Spoke Set).
17x2,50 Excel rim with article number 58-512 fit this spoke set.
Nipple size: 6,5x20 mm. (9G/250)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,6x164 mm, have article number 50-0605-1
One spoke and nipple, 3,6x169 mm, have article number 50-0605-2
Fits the following models:
YAMAHA
XT 660 R 04-18
XT 660 X 04-18
XT 660 Z Ténéré 08-16
For 17x2,50 and 17x2,75 rear wheel with hub 5VK-25311-00 and 56P-F5311-00.
This spoke set has 36 spokes with spoke nipples.
NOTE! For MT rim profile.
Spoke size: 18 spokes of 3,6x164 mm. Inner and outer on sprocket side.
Spoke size: 18 spokes of 3,6x169 mm. Inner and outer on brake disc side.
OEM Ref. 5VK-F5304-00 replaced by 5VK-F5304-01 (Spoke Set).
17x2,50 Excel rim with article number 58-512 fit this spoke set.
Nipple size: 6,5x20 mm. (9G/250)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,6x164 mm, have article number 50-0605-1
One spoke and nipple, 3,6x169 mm, have article number 50-0605-2
