Spoke Set Yamaha YZ 125 19-inch 89- Rear Wheel
990 SEK per Each
CC Products spokes are made in our spoke machine in our own warehouse in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-0031
CC Products stainless spoke set
Fits the following models:
YAMAHA
DT 200 WR 91-96
TT 250 R 96-02
TT-R 250 93-06
TT-R 250 Raid 94-96
WR 250 F 03-
WR 400 F 98-01
WR 426 F 02-03
WR 450 F 04
WR 500 Z 91-93
YZ 125 89-
YZ 250 89-
YZ 250 X 15-
YZ 250 F 01-08
YZ 250 FX 16-24
YZ 250 WR 89-91
YZ 400 F 99-00
YZ 426 F 01-02
YZ 450 F 03-08
YZ 450 FX 16-23
For 19-inch rear wheel with hub 2VN-25311-00-98 replaced by 4EW-25311-00 replaced by 5ET-25311-00 and 4GY-25311-00-35.
This spoke set has 36 spokes with spoke nipples.
Spoke size: 18 spokes of 4x204 mm, outer spoke on both sides.
Spoke size: 18 spokes of 4x206 mm, inner spoke on both sides.
OEM Ref. 3JD-25304-00 (Spoke Set) replaced by 4XM-25304-00 replaced by 5HD-25304-00.
Nipple size: 7,6x20 mm. (8G/300)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 4x204 mm, have article number 50-0031-1
One spoke and nipple, 4x206 mm, have article number 50-0031-2
Fits the following models:
YAMAHA
DT 200 WR 91-96
TT 250 R 96-02
TT-R 250 93-06
TT-R 250 Raid 94-96
WR 250 F 03-
WR 400 F 98-01
WR 426 F 02-03
WR 450 F 04
WR 500 Z 91-93
YZ 125 89-
YZ 250 89-
YZ 250 X 15-
YZ 250 F 01-08
YZ 250 FX 16-24
YZ 250 WR 89-91
YZ 400 F 99-00
YZ 426 F 01-02
YZ 450 F 03-08
YZ 450 FX 16-23
For 19-inch rear wheel with hub 2VN-25311-00-98 replaced by 4EW-25311-00 replaced by 5ET-25311-00 and 4GY-25311-00-35.
This spoke set has 36 spokes with spoke nipples.
Spoke size: 18 spokes of 4x204 mm, outer spoke on both sides.
Spoke size: 18 spokes of 4x206 mm, inner spoke on both sides.
OEM Ref. 3JD-25304-00 (Spoke Set) replaced by 4XM-25304-00 replaced by 5HD-25304-00.
Nipple size: 7,6x20 mm. (8G/300)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 4x204 mm, have article number 50-0031-1
One spoke and nipple, 4x206 mm, have article number 50-0031-2
