Spoke and nipple DR 800 21-inch 91-97 Front Wheel
50 SEK per Each
CC Products spokes are made in our spoke machine in our own warehouse in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-0213-2
CC Products Stainless spoke and nipple 3,6x227 mm
Fits the following models:
SUZUKI
DR 650 R 92-94
DR 650 RE 94-95
DR 650 REU 94-95
DR 650 RSE 91-96
DR 650 RSEU 91-96
DR 650 RU 92-94
DR 650 SE 92->
DR 650 SEU 96-00
DR 800 S 91-97
DR 800 SU 91-97
XF 650 97-99
XF 650 U 97-99
XF 650 Freewind 97-02
For 21-inch front wheel with hub 54111-31D00 replaced by 54111-31D01 and 54111-31D10.
NOTE! For hub with 6-bolt brake disc, see pictures.
There is 2 different spokes in this wheels and a total of 36 spokes.
Spoke size: 18 of 3,6x227 mm. Inner spoke on both sides.
OEM Ref. 55320-31D00 (Spoke Set).
Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418.
Nipple size: 7,0x20 mm. (9G/275)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
Fits the following models:
SUZUKI
DR 650 R 92-94
DR 650 RE 94-95
DR 650 REU 94-95
DR 650 RSE 91-96
DR 650 RSEU 91-96
DR 650 RU 92-94
DR 650 SE 92->
DR 650 SEU 96-00
DR 800 S 91-97
DR 800 SU 91-97
XF 650 97-99
XF 650 U 97-99
XF 650 Freewind 97-02
For 21-inch front wheel with hub 54111-31D00 replaced by 54111-31D01 and 54111-31D10.
NOTE! For hub with 6-bolt brake disc, see pictures.
There is 2 different spokes in this wheels and a total of 36 spokes.
Spoke size: 18 of 3,6x227 mm. Inner spoke on both sides.
OEM Ref. 55320-31D00 (Spoke Set).
Loxeal 10 ml. thread lock can be purchased separately on article number 52-2418.
Nipple size: 7,0x20 mm. (9G/275)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
