Spoke Set Suzuki FR 50 17-inch 1981 Front Wheel (Drum brake)
650 SEK per Set
CC Products spokes are made in our spoke machine in our own factory in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-1841
CC Products stainless spoke Set
Fits the following mopeds:
SUZUKI
AS 50 1971
FR 50 1981
FR 80 75-83
K 50 75-91
M 15 1968
M 31 1968
TS 50 71-74
U 70 67-68
For 17-inch front wheel with hub 54110-046001 replaced by 54110-46002 (Drum brake).
This spoke set has 36 spokes with spoke nipples.
Spoke size: 18 spokes of 3,2x161 mm. Inner spoke on both sides.
Spoke size: 18 spokes of 3,2x161 mm. Outer spokes on both sides.
OEM Ref. 55301-01812 replaced by 55320-01012 (Spoke set).
Nipple size: 5,7x15 mm. (10G/225)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,2x161 mm inner spoke, have article number 50-1841-1
One spoke and nipple, 3,2x161 mm outer spoke, have article number 50-1841-2
Fits the following mopeds:
SUZUKI
AS 50 1971
FR 50 1981
FR 80 75-83
K 50 75-91
M 15 1968
M 31 1968
TS 50 71-74
U 70 67-68
For 17-inch front wheel with hub 54110-046001 replaced by 54110-46002 (Drum brake).
This spoke set has 36 spokes with spoke nipples.
Spoke size: 18 spokes of 3,2x161 mm. Inner spoke on both sides.
Spoke size: 18 spokes of 3,2x161 mm. Outer spokes on both sides.
OEM Ref. 55301-01812 replaced by 55320-01012 (Spoke set).
Nipple size: 5,7x15 mm. (10G/225)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,2x161 mm inner spoke, have article number 50-1841-1
One spoke and nipple, 3,2x161 mm outer spoke, have article number 50-1841-2
