Spoke Set Suzuki TS 50 X 21-inch 84-01 Front Wheel
650 SEK per Set
CC Products spokes are made in our spoke machine in our own factory in Sweden. We use Swedish stainless steel spoke wire with a tensile strength of 1450 N/mm2 and a yield strength of 1250 N/mm2!
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
The spokes are manufactured as accurately as possible to OEM specifications and sold as replacement spokes for original hubs and rims unless otherwise stated.
If you do not find what you are looking for then we can manufacture spokes according to sample or drawing.
(Optional)
- Secure payment by card
- E-mail us, we reply swiftly! order@wheelsandparts.se
- Fast delivery!
Description
Article no.: 50-1863
CC Products stainless spoke Set
Fits the following mopeds:
SUZUKI
TS 50 X 84-01
For 21-inch front wheel with hub 54110-13602.
This spoke set has 36 spokes with spoke nipples.
Spoke size: 9 spokes of 3,2x206 mm. Inner spoke on brake side.
Spoke size: 9 spokes of 3,2x206 mm. Outer spokes on brake side.
Spoke size: 9 spokes of 3,2x232 mm. Outer spoke on small side.
Spoke size: 9 spokes of 3,2x234 mm. Inner spokes on small side.
OEM Ref. 55320-13610 (Spoke set).
Nipple size: 6,5x20 mm. (10G/250)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,2x206 mm inner spoke, have article number 50-1863-1
One spoke and nipple, 3,2x206 mm outer spoke, have article number 50-1863-2
One spoke and nipple, 3,2x232 mm, have article number 50-1863-3
One spoke and nipple, 3,2x234 mm, have article number 50-1863-4
Fits the following mopeds:
SUZUKI
TS 50 X 84-01
For 21-inch front wheel with hub 54110-13602.
This spoke set has 36 spokes with spoke nipples.
Spoke size: 9 spokes of 3,2x206 mm. Inner spoke on brake side.
Spoke size: 9 spokes of 3,2x206 mm. Outer spokes on brake side.
Spoke size: 9 spokes of 3,2x232 mm. Outer spoke on small side.
Spoke size: 9 spokes of 3,2x234 mm. Inner spokes on small side.
OEM Ref. 55320-13610 (Spoke set).
Nipple size: 6,5x20 mm. (10G/250)
If the spoke nipple holes are smaller or larger you may need to change spoke nipples to another size.
One spoke and nipple, 3,2x206 mm inner spoke, have article number 50-1863-1
One spoke and nipple, 3,2x206 mm outer spoke, have article number 50-1863-2
One spoke and nipple, 3,2x232 mm, have article number 50-1863-3
One spoke and nipple, 3,2x234 mm, have article number 50-1863-4
